A 4-post servo hydraulic press is widely used as a hemming press for precision edge folding of sheet metal panels in automotive, appliance, and industrial manufacturing.

Hemming is the process of folding a panel edge over another panel to create a smooth, reinforced seam.

Automotive Hemming Applications

In automotive manufacturing, a 4-post servo hemming press is commonly used for door panel hemming, hood hemming, trunk lid edge folding, tailgate hemming, quarter panel flange forming, and roof panel edge closing. These operations require even pressure distribution across large stamped panels to avoid surface defects while maintaining tight dimensional tolerances.

The open 4-post design provides full accessibility for large dies and automated loading systems, making it well suited for automotive OEM production lines, EV body panel manufacturing, and Tier 1 stamping facilities operating at high throughput levels.

Appliance & Industrial Panel Hemming

Beyond automotive applications, servo hydraulic hemming presses are widely used in the production of washer and dryer cabinet panels, refrigerator door panels, metal enclosures, electrical cabinets, and industrial housings. These applications demand consistent seam quality and clean finished edges, particularly when panels are coated or visible in final assemblies.

The precision control of a servo-driven hydraulic system helps prevent coating damage, material wrinkling, or uneven folding when processing complex geometries.

Materials Processed

A 4-Post Servo Hemming Press can process a wide range of sheet metal materials, including mild steel, high-strength steel (HSS), aluminum, galvanized sheet, and coated sheet metal. Controlled tonnage and programmable motion profiles allow manufacturers to adjust forming characteristics based on material thickness, yield strength, and surface finish requirements.

Why Use a 4-Post Servo Hemming Press?

Manufacturers choose a 4-post servo hydraulic hemming press because it provides controlled tonnage that minimizes panel distortion, programmable speed profiles for both pre-hemming and final hemming stages, adjustable dwell time for adhesive-assisted hemming processes, and even load distribution across large panels. High repeatability ensures consistent seam quality from part to part, which is essential in automated production environments.

A 4-Post Servo Hydraulic Press is widely used as an assembly press for controlled press-fit, insertion, and component joining applications across automotive, aerospace, industrial, and electronics manufacturing. These assembly operations require precise force control, depth accuracy, and repeatable positioning to ensure proper component alignment without material damage.

Servo-controlled hydraulic systems allow programmable tonnage limits, adjustable insertion speeds, and real-time monitoring of force and displacement. This level of precision is critical in applications where over-pressing can damage components, distort assemblies, or compromise long-term product performance.

Press-Fit Applications

In press-fit applications, the 4-post servo assembly press is commonly used for bearing press-fit operations, bushing insertion, shaft insertion, gear pressing, pin insertion, stud installation, and sleeve assembly. These processes demand consistent force application and controlled travel to maintain part integrity and dimensional accuracy.

Such operations are widely performed in automotive powertrain assembly, EV motor assembly, and industrial machinery manufacturing environments where repeatability and traceability are essential.

Electric & EV Assembly Applications

In electric and EV manufacturing, servo hydraulic assembly presses are used for electric motor stator assembly, rotor shaft pressing, EV battery module compression, busbar insertion, and terminal pressing. Electrical components require highly controlled force application because excessive pressure can damage windings, insulation, or conductive materials.

The programmable motion profile of a 4-post servo press ensures gradual force buildup, precise final positioning, and documented force-displacement curves for quality validation and process control.

Industrial & Heavy Equipment Assembly

In industrial and heavy equipment manufacturing, a 4-Post Servo Hydraulic Press supports hydraulic component assembly, pump housing assembly, cylinder rod insertion, structural component joining, and sub-assembly calibration. Even load distribution across the press bed ensures consistent alignment and reduces stress concentrations during large assembly operations.

The open 4-post design also allows integration with automation systems and robotic loading, supporting high-throughput production lines.

Aerospace & Precision Assembly

In aerospace and precision manufacturing, assembly presses are used for structural bracket installation, precision fastener insertion, landing gear component assembly, and controlled-force joining of lightweight materials. These applications require extremely tight tolerances and validated process data to meet industry compliance standards.

Servo hydraulic systems provide programmable tonnage control and integrated quality data logging, enabling manufacturers to track every assembly cycle and verify force parameters for traceability.

Why Use a 4-Post Servo Assembly Press?

Manufacturers choose a 4-post servo hydraulic assembly press because it offers programmable tonnage limits, force-displacement monitoring, adjustable insertion speeds, consistent press depth control, integrated quality data logging, and even load distribution across large assemblies. This combination of precision and repeatability makes it ideal for automated production environments requiring both performance and documentation.

The MTP-SV Series 4-Post Servo Hydraulic Press (35–200 ton) is ideal for light to medium-duty metal forming operations requiring controlled tonnage, adjustable stroke, and even load distribution across the entire platen.

The servo-driven hydraulic system allows programmable motion profiles and controlled forming speed, making it ideal for applications where material integrity, dimensional accuracy, and surface quality must be maintained throughout the forming cycle.

Typical Metal Forming Applications

A 4-Post Servo Hydraulic Press is commonly used for bracket forming, structural reinforcement panel forming, light gauge steel forming, aluminum part forming, shallow draw components, coining operations, flattening and leveling processes, panel stiffener forming, and custom fabricated components. These operations require controlled pressure application and uniform load distribution to prevent distortion and ensure consistent part geometry.

Because the press provides even force across the full bed area, it is particularly effective for forming larger panels or parts with asymmetrical loading conditions.

Industries Served

This type of servo hydraulic press supports manufacturers across automotive Tier 1 and Tier 2 suppliers, EV component manufacturers, industrial machinery manufacturers, appliance manufacturers, fabrication shops, and general metal stamping facilities. The flexibility of programmable tonnage and adjustable stroke makes it adaptable to a wide range of forming requirements within both low-volume custom production and repeatable batch manufacturing environments.

Materials Commonly Processed

The MTP-SV Series can process mild steel, aluminum, stainless steel, galvanized sheet, and high-strength light gauge steel. Controlled forming speed and programmable pressure curves allow manufacturers to tailor the forming cycle based on material thickness, yield strength, and surface finish requirements.

This capability is especially important when forming lightweight materials or coated sheet metal where excessive force or rapid motion could cause cracking, wrinkling, or coating damage.

Why a 4-Post Servo Hydraulic Press for Metal Forming?

Manufacturers select a 4-Post Servo Hydraulic Press for metal forming because it provides even force distribution across the full bed, programmable tonnage control, adjustable stroke length, controlled forming speed, reduced panel distortion, and repeatable forming accuracy. These advantages make it suitable for small-to-mid production runs where precision and consistency are more important than high-speed output.

Ideal Tonnage Range (MTP-SV Series)

Within the MTP-SV Series, the 35–75 ton range is typically used for small brackets, light forming, and precision parts. The 100–150 ton range supports medium structural components and panel forming applications. The 200 ton configuration is suited for larger reinforcement panels and heavier gauge forming operations that require greater force capacity while maintaining controlled motion.

• 35–75 ton: Small brackets, light forming, precision parts

• 100–150 ton: Medium structural components and panels

• 200 ton: Larger reinforcement panels and heavier gauge forming

The MTP-SV Series 4-Post Servo Hydraulic Press (35–200 ton) can be configured for controlled deep drawing applications involving light to medium gauge materials.

Servo-controlled hydraulics provide programmable motion profiles and stable tonnage throughout the stroke, making this press well suited for precision deep draw forming rather than high-speed production stamping. The ability to adjust speed, pressure buildup, and dwell time is critical when forming cylindrical or cup-shaped components that demand dimensional consistency and surface integrity.

Typical Deep Drawing Applications

A 4-Post Servo Hydraulic Press is commonly used to produce small housings, metal cups and cylindrical components, enclosures, automotive sub-components, electrical junction box housings, battery casings, appliance components, and industrial covers. These parts require smooth material flow and consistent forming pressure to maintain uniform wall thickness and structural integrity.

The open 4-post design provides accessibility for tooling adjustments and allows integration with automated loading systems in medium-volume production environments.

Materials Commonly Drawn

This deep drawing configuration processes mild steel, stainless steel, aluminum, and light gauge high-strength steel. Controlled tonnage and programmable speed profiles enable manufacturers to tailor forming characteristics based on material ductility, thickness, and surface finish requirements. This is particularly important when drawing stainless steel or aluminum components where tearing and surface defects can occur if force application is not properly managed.

Why Servo Hydraulic for Deep Drawing?

Deep drawing operations require slow initial contact, controlled material flow, stable tonnage throughout the full stroke, and adjustable dwell time at bottom dead center. A servo hydraulic press provides programmable speed profiles, consistent forming pressure, reduced tearing risk, improved surface finish, and lower distortion compared to mechanical presses operating at fixed speeds.

Force-displacement control also allows manufacturers to fine-tune draw cycles and validate forming performance, improving part consistency and reducing scrap rates.

Ideal Tonnage Range for Deep Drawing (MTP-SV Series)

Within the MTP-SV Series, the 35–75 ton range is typically suited for small cups and shallow cylindrical parts. The 100–150 ton range supports medium-depth components requiring greater forming pressure and stroke control. The 200 ton configuration is appropriate for larger small-to-mid draw applications where additional force capacity is necessary while maintaining programmable motion accuracy.

• 35–75 ton: Small cups, shallow cylindrical parts

• 100–150 ton: Medium depth components

• 200 ton: Larger small-to-mid draw applications

Not Intended For

• Large automotive body panels

• Deep structural chassis components

• High-speed production coil-fed drawing

• Multi-stage transfer drawing systems
