HOT WATER HIGH FLOW -
TEMPERATURE CONTROL UNITS
THC-HW-D SERIES (DUAL ZONE)
Hot water temperature control units are usually used for applications such as injection molding, extrusion, heated, rollers, blow molding, rubber processing, chemical and pharmaceutical processes, food and beverage production, printing and lamination and also testing and R&D labs.
Our THC-HW-D Dual Zone water temperature control units feature both heating and cooling and have an operating range of 95° - 300° F (35° - 150° C)
| Model | Heater | Zones |
| THC-HW-D-9 | 9 KW (X2) | Dual |
| THC--HW-D-18 | 18 kW (x2) | Dual |
| THC-HW-D-24 | 24 kW (x2) | Dual |
| THC-HW-D-36 | 36 kW (x2) | Dual |
| THC-HW-D-48 | 48 kW (x2) | Dual |
THC-HW-S (SINGLE ZONE)
Our THC-HW-S SIngle Zone water temperature control units feature both heating and cooling and have an operating range of 95° - 300° F (35° - 150° C)
MAJOR BENEFITS AND FEATURES:
- More standard features than any other competitor
- Extremely competitive pricing
- PLC control with color HMI screen
- Job preset memory
- Heating and Cooling for maximum flexibility
- Solid, robust construction
- Durable flanged ball valves
- Increased operator safety
- Auto exhaust function
- Multi-stage adjustable heating
- Remote diagnostics/troubleshooting via the internet
- Sealed system which does not allow oil to oxidize
- Integrated fault alarm and signal
- Highly visible temperature reading from a distance
- Multi language operator interface
- Visible and audible alarms
- Auto syncing with machine process
- Automatic service schedule reminders
- Comprehensive I/O and fault screens
- Firmware updates
TECHNICAL OVERVIEW
A hot water high‑flow temperature control unit is engineered for applications that require rapid heat transfer, tight temperature stability, and consistent thermal performance across demanding industrial processes. Unlike standard water TCUs, high‑flow systems use larger pumps and increased circulation rates to deliver faster heat‑up times, improved temperature uniformity, and superior responsiveness to process changes. This makes them ideal for molds, platens, rolls, and tooling with complex channels or high thermal loads. The system’s closed‑loop design ensures efficient heat transfer while minimizing scale buildup and maintenance. For manufacturers seeking precise, repeatable temperature control with maximum flow capacity, a high‑flow water TCU provides the performance and reliability needed for modern production environments.
High‑flow water TCUs offer significant advantages when processes require rapid temperature recovery, uniform heating, or high‑capacity circulation. Standard TCUs may struggle to maintain consistent temperatures in large molds, multi‑zone tooling, or equipment with long or restrictive water channels. A high‑flow system overcomes these limitations by delivering greater pump output and higher circulation rates, ensuring even heat distribution and faster response to thermal demand. This improves part quality, reduces cycle variation, and enhances process stability. High‑flow water TCUs also operate at safe, moderate pressures while providing excellent energy efficiency. For operations where temperature uniformity and throughput are critical, a high‑flow system is the superior choice.
A hot water high‑flow TCU combines high‑capacity pumping, precise temperature control, and robust industrial construction to deliver exceptional thermal performance. Its high‑flow pump ensures rapid circulation through complex or large tooling, while advanced controllers maintain tight temperature tolerances. Many units include stainless‑steel piping, high‑efficiency heaters, automatic venting, and safety features such as over‑temperature protection and low‑flow shutdown. The system’s ability to maintain uniform heating reduces defects, improves cycle consistency, and enhances overall process efficiency. Hot water high‑flow TCUs are widely used in plastics, rubber, composites, packaging, and general industrial heating applications where stable, high‑volume water flow is essential.
Applications of the Hot Water Temperature Control Unit
High‑flow water TCUs are ideal for molds with long, restrictive, or complex cooling channels that require rapid, uniform heat transfer. The increased circulation rate ensures consistent mold temperatures, faster heat‑up times, and improved cycle stability. This is especially valuable for large molds, multi‑cavity tools, and high‑precision parts where temperature variation can cause warpage, dimensional drift, or cosmetic defects. High‑flow systems help maintain tight process control and improve overall part quality.
Many thermoforming, laminating, and press‑based processes rely on stable, evenly distributed heat across large platens or heated surfaces. A high‑flow water TCU delivers the volume and velocity needed to maintain uniform temperatures across wide or multi‑zone tooling. This improves material consistency, reduces hot and cold spots, and enhances surface finish. Manufacturers use high‑flow systems to support thermoforming sheets, composite layups, laminating lines, and heated press operations.
Extrusion and blow‑molding processes require precise temperature regulation to maintain melt quality, wall thickness, and material stability. High‑flow TCUs provide rapid heat transfer to barrels, dies, and tooling, ensuring consistent processing temperatures even under fluctuating thermal loads. The increased flow rate helps prevent temperature lag, improves product uniformity, and reduces scrap — especially in high‑throughput production environments.
High‑flow water TCUs are used to heat tanks, reactors, and process circuits where rapid temperature recovery and uniform heating are essential. Applications include adhesives, coatings, food‑grade materials, chemical mixtures, and water‑based industrial fluids. The high‑flow design ensures efficient heat transfer throughout the system, reduces temperature gradients, and supports stable, repeatable processing. This makes high‑flow TCUs a reliable solution for continuous‑duty industrial heating.
Frequently Asked Questions about Hot Water Temperature Control Unit
A high‑flow water TCU delivers significantly greater circulation volume, allowing heat to move rapidly and uniformly through molds, platens, rolls, and process circuits. Standard TCUs may struggle with long or restrictive channels, causing temperature lag or uneven heating. High‑flow systems overcome these limitations by maintaining higher flow velocity, improving thermal uniformity, reducing cycle variation, and enhancing part quality. This makes them ideal for large molds, multi‑zone tooling, and high‑demand industrial processes.
High‑flow TCUs are best suited for applications requiring rapid heat transfer and tight temperature stability. Common uses include injection molding, blow molding, extrusion, thermoforming, laminating, composite processing, and heating of tanks or vessels. These processes rely on consistent thermal performance to maintain material quality, dimensional accuracy, and repeatability. High‑flow circulation ensures uniform heating even in complex or high‑thermal‑load systems.
By delivering higher circulation rates, a high‑flow TCU minimizes temperature gradients and ensures uniform heat distribution across tooling or process surfaces. This reduces hot and cold spots, improves cycle‑to‑cycle consistency, and enhances material stability. Faster heat‑up and recovery times also reduce process variation, leading to better dimensional accuracy, improved surface finish, and fewer defects. For manufacturers focused on quality and repeatability, high‑flow systems provide a measurable performance advantage.
High‑flow water TCUs include multiple safety systems to protect operators and equipment. Typical features include over‑temperature protection, low‑flow shutdown, pressure‑relief valves, automatic venting, and pump‑protection controls. Many units also incorporate stainless‑steel piping, leak‑resistant designs, and advanced controllers that monitor system performance in real time. These safeguards ensure reliable operation and reduce the risk of overheating, pump damage, or system failure.
Yes — hot water high‑flow temperature control units are available to customers throughout the United States, Canada, and Mexico. Manufacturers across North America rely on these systems for plastics processing, rubber molding, extrusion, laminating, and general industrial heating. Regional availability ensures faster delivery, dependable technical support, and access to replacement parts. Units can be configured with various pump sizes, heating capacities, and control packages to match specific process requirements.
