Single Point Straight Sided Servo Press
SINGLE POINT STRAIGHT SIDED SERVO PRESS
The MSE‑SV Series Single Point Straight‑Sided Servo Presses offer the robust construction of a precision straight‑side frame with the dynamic control capabilities of servo drive technology. Built around a steadfast single‑point straight‑side structure, these stamping presses deliver excellent rigidity and large die access. Integrated servo control allows full programmability of slide motion, including adjustable speeds, dwell timing, and forming profiles—enabling precise part production, enhanced die longevity, and significant energy savings. The MSE‑SV is perfectly suited for advanced stamping, forming, embossing, and progressive die applications across automotive, appliance, electrical, and general metalworking industries.
TECHNICAL OVERVIEW
A Single‑Point Straight‑Sided Servo Press is engineered for applications that demand exceptional accuracy, rigidity, and programmable forming control. The straight‑sided frame provides superior structural stability compared to C‑frame designs, minimizing deflection and ensuring consistent slide parallelism during high‑tonnage or precision forming operations. With servo technology, operators can fully customize stroke profiles, forming velocity, dwell time, and approach speed to match the exact requirements of each job. This level of control improves part quality, reduces shock loads, and extends tool life. The single‑point configuration is ideal for small to medium‑sized components requiring tight tolerances, clean edges, and repeatable accuracy. Manufacturers choose this press when they need a high‑performance, rigid platform capable of delivering precision across demanding stamping and forming applications.
A straight‑sided servo press offers several advantages for manufacturers who require maximum rigidity, accuracy, and process control. Unlike C‑frame presses, the straight‑sided structure eliminates angular deflection and maintains perfect alignment between the slide and bolster, even under heavy loads. This makes it ideal for precision blanking, progressive die stamping, and forming operations where dimensional consistency is critical. The servo drive system enhances flexibility by allowing operators to program custom motion profiles, slow‑speed forming, dwell at bottom dead center, and optimized cutting speeds. This reduces tool wear, improves surface quality, and increases production efficiency. For facilities that demand both structural strength and advanced motion control, a straight‑sided servo press provides a superior combination of stability, accuracy, and versatility.
This Single‑Point Straight‑Sided Servo Press combines a rigid frame, advanced servo motion control, and a precision‑guided slide to deliver exceptional forming performance. The straight‑sided design ensures minimal deflection and excellent slide parallelism, making it ideal for high‑accuracy stamping, blanking, and forming applications. The servo system allows operators to program stroke length, forming velocity, dwell positions, and approach speed, enabling optimized performance for a wide range of materials and tooling. Additional features may include high‑efficiency motors, overload protection, precision lubrication systems, and compatibility with coil feeders and automation equipment. Manufacturers benefit from improved part quality, reduced scrap, extended tool life, and lower energy consumption. This press is engineered for operations that require repeatable accuracy and flexible, high‑performance forming capability.
9 STAMPING MODES
Take Full Control
This servo press is equipped with 9 built-in stamping modes, allowing users to select the most suitable motion curve for each application. This ensures high precision, improved efficiency, and optimized energy savings.
SERVO DRIVE SYSTEM
Greater Accuracy And Efficiency
Our servo system allows for greater accuracy of the moving platen stopping position and offers very significant energy savings.
GET PARTS ANYWHERE
Open Source Control System
Our control systems are made with open source, readily available components. We use no custom-made OEM parts.
IMPROVED SERVICE LIFE
High Fequency Quenching
We use a high frequency quenching on our slide guides which reaches over HRC 48. Rail grinding is above RA 0.4 and the average flatness is 0.03 mm/m2. The result is reduced wear, sustained precision and longer service life.
STRENGTH AND WEAR RESISTANCE
Bronze Worm Gear
Bronze worm gears reduce the probability of seizure and greatly reduce the process of die adjustment. The bronze-copper alloy (ZQSN10-1) extend the service life when compared to cast iron worm gears.
MORE STAMPING
Less Seizing
We use a sintered TM-3 copper alloy ball seat as opposed to cast iron. The TM-3 copper alloy has a surface strength of 1000 kgf/C m2. This alloy reduces the probability of seizure and at the same time extends the service life of this part.
LESS WEAR AND TEAR
Copper Sleeves
The all bronze-copper alloy sleeves are made of Tin, Phosphorus Bronze ZQSN10-1 and are about 1.5 times stronger then just copper BC6. The result is reduced wear.
STRONGER AND BIGGER
Hardened Crankshaft
Our crankshafts are made of high strength 42 CrMo alloy and are larger than most. They are forged, heat treated and inspected for flows. The result is that the strength is 1.3 times higher than that of 45 steel and breaking is reduced.
HARDENED AND STRONGER
Chromium Plated Thimble
Our thimbles are chromium plated with a surface between RA 0.4 and RA 0.8. They are then hardened to HRC 48. This provides an excellent oil seal to ensure seal life.
LESS WEAR ON TOOTH SURFACES
Hardened Gear Shaft
The gear shaft is made of high strength 42CrMo alloy and all tooth surfaces are treated with intermediate frequency which increases hardness. The advantage of this is less wear on tooth surfaces and higher meshing precision.
IMPROVED SERVICE LIFE
High Frequency Quenched Gear Drive
We use a high frequency quenching on our gear drives which reaches over HRC 48. Rail grinding is above RA 0.4 and the average flatness is 0.03 mm/m2. The result is reduced wear, sustained precision and longer service life.
Safety Light Curtains
WORKER SAFETY SHOULD NOT BE AN OPTION FOR A PRESS
We are very serious about worker safety. That is why all our presses include full size CAT4 safety light curtains as a standard feature. The light curtains work along with the other safety features to ensure worker safety at all times.
MORE OIL, LESS WEAR
Bigger Oil Piping
We use 8 mm diameter copper lubrication pipes to ensure proper lubrication on all critical points. The larger and higher gauge pipes reduce the possibility of breaking and ensure a constant flow of oil.
OPTIMIZED STRUCTURE.
Finite Element Analysis (FEA)
Through SolidWorks finite element analysis (FEA) we optimize the press structure and refine the design for maximum performance.
HIGHEST RETURN ON INVESTMENT
We Give You More Press For Your Money.
To be competitive today’s economy requires that manufactures run their operations more efficiently and cost effectively than ever before. We offer the highest ROI (return on investment) in the industry. MetalPress gives you high-quality products for a reasonable investment and with more features than any other company. Simply put, we give you the most bang for your buck!
REMOTE SERVICE
We Can Remotely Troubleshoot Your Stamping Press from Our Facility.
Our Double Straight Sided Stamping Presses include a Remote Connectivity Unit which allows our press technicians to remotely check the performance of the press, make any needed changes to the program or HMI, or to troubleshoot it directly from our service center. The customer is only required to connect the unit to the Internet via an Ethernet cable. We handle the rest.
HIGH QUALITY COMPONENTS
We Use Brand Name Components You Know, Already Use and Trust.
We use only the finest quality components that are open source, and readily available locally in your area, or from our online parts store. We do not use any impossible to find proprietary components.
INDUSTRY 4.0 REMOTE MONITORING
Remotely Monitor Your Stamping Press Performance From Any Device.
As an option, all our presses are available with Industry 4.0 remote performance monitoring units which feature a custom dashboard. You can not only monitor press performance, but you can be notified before an issue occurs. Included are condition based maintenance reminders and shift performance statistics. Minimize impact of emergencies and maximize press uptime, and productivity. Monitor what is going on with the stamping press and your production efficiency from any device, anywhere in the world.
EIGHT STANDARD SIZES
Flexible Range of Applications.
Available from 120 tons all the way up to 660 tons
| Model | US Tons | Slide Size (in) | Bolster Size (in) |
| MSE-SV-120 | 120 | 29.5 x 27.6 | 29.5 x 31.5 |
| MSE-SV-175 | 175 | 29.5 x 27.6 | 33.5 x 31.5 |
| MSE-SV-220 | 220 | 29.5 x 27.6 | 35.4 x 31.5 |
| MSE-SV-275 | 275 | 31.5 x 31.5 | 39.4 x 35.4 |
| MSE-SV-330 | 330 | 35.4 x 35.4 | 43.3 x 39.4 |
| MSE-SV-440 | 440 | 39.4 x 35.4 | 47.2 x 39.4 |
| MSE-SV-550 | 550 | 47.2 x 39.4 | 55.1 x 39.4 |
| MSE-SV-660 | 660 | 47.2 x 39.4 | 55.1 x 39.4 |
| Model | Metric Tons | Slide Size (mm) | Bolster Size (mm) |
| MSE-SV-120 | 110 | 750 x 700 | 750 x 800 |
| MSE-SV-175 | 160 | 750 x 700 | 850 x 800 |
| MSE-SV-220 | 200 | 750 x 700 | 900 x 800 |
| MSE-SV-275 | 250 | 800 x 800 | 1000 x 900 |
| MSE-SV-330 | 300 | 900 x 900 | 1100 x 1000 |
| MSE-SV-440 | 400 | 1000 x 900 | 1200 x 1000 |
| MSE-SV-550 | 500 | 1200 x 1000 | 1400 x 1000 |
| MSE-SV-660 | 600 | 1200 x 1000 | 1400 x 1000 |
Applications of the Single Point Straight-Sided Servo Press
The Single‑Point Straight‑Sided Servo Press is ideal for automotive components that demand exceptional accuracy and consistent forming pressure. The straight‑sided frame eliminates angular deflection, ensuring perfect slide alignment during high‑tonnage or precision operations. This makes it ideal for producing brackets, small housings, transmission components, EV battery hardware, and structural stampings requiring tight tolerances. The servo drive allows operators to fine‑tune forming velocity, dwell, and slide motion to reduce tool wear and improve part consistency. Automotive suppliers rely on this press for both high‑speed progressive stamping and slow‑forming operations where material control is critical. Its rigidity and programmable motion make it a top choice for precision automotive manufacturing.
Electrical and electronics manufacturers use this press for producing intricate, thin‑gauge components that require clean edges and repeatable accuracy. The straight‑sided structure provides superior stability for stamping connectors, terminals, shielding components, micro‑precision parts, and small enclosures. Servo motion control enables slow‑speed forming, controlled dwell, and optimized cutting profiles—essential for copper, aluminum, and specialty alloys. The rigid frame ensures consistent slide parallelism, improving dimensional accuracy across long production runs. This press integrates easily with coil feeders and robotic handling systems, making it ideal for high‑volume electronics production where precision and repeatability are non‑negotiable.
The Single‑Point Straight‑Sided Servo Press is well‑suited for appliance and consumer goods manufacturing, where consistent quality and precise forming are essential. Its rigid frame and servo‑controlled motion make it ideal for stamping brackets, hinges, covers, frames, and internal hardware from stainless steel, aluminum, and coated sheet metals. The programmable stroke allows operators to optimize forming profiles for shallow draws, bending, blanking, and piercing. The straight‑sided design ensures uniform force distribution, improving part consistency and extending tool life. Manufacturers benefit from reduced scrap, improved surface quality, and reliable performance across medium‑volume production lines.
For precision blanking applications, the straight‑sided servo press provides the rigidity and controlled motion needed for clean, accurate edges. The servo drive allows operators to slow the slide during the cutting phase, reducing shock and improving edge quality. This makes it ideal for producing washers, shims, plates, electrical contacts, and precision metal inserts. The straight‑sided frame ensures minimal deflection, maintaining consistent cutting performance across the entire die surface. Manufacturers benefit from reduced tool wear, improved dimensional accuracy, and lower scrap rates. Whether working with steel, aluminum, copper, or specialty alloys, this press delivers the fine‑edge performance required for demanding blanking operations.
The Single‑Point Straight‑Sided Servo Press excels in progressive die stamping applications where speed, timing, and precision are essential. The rigid frame maintains excellent slide parallelism, ensuring consistent part quality across multi‑stage dies. Servo motion control allows operators to program acceleration, deceleration, dwell, and forming velocity to match the requirements of complex progressive tooling. This results in smoother transitions between stations, reduced shock loads, and improved tool longevity. The press integrates seamlessly with coil feeders, straighteners, and automated transfer systems. For manufacturers running high‑speed progressive lines, this press provides the stability, accuracy, and flexibility needed for efficient production.
The straight‑sided servo press is highly effective for piercing and punching operations that require precise alignment and consistent force. The rigid frame and precision‑guided slide reduce deflection, improving hole quality and extending tool life. Servo motion allows for controlled impact and optimized cutting profiles, making it ideal for components with multiple holes, slots, or cutouts. This includes brackets, electrical terminals, appliance hardware, and small automotive parts. The press supports both manual and automated workflows, and its programmable stroke enhances repeatability. For manufacturers seeking high‑accuracy hole‑making with minimal variation, this press offers a dependable and efficient solution.
The Single‑Point Straight‑Sided Servo Press is well‑suited for shallow draw and controlled forming applications where precision and material control are essential. The servo‑driven slide allows operators to fine‑tune forming velocity, dwell time, and slide position to reduce wrinkling, tearing, and material distortion. The straight‑sided frame ensures uniform force distribution, improving forming consistency and part quality. This makes the press ideal for producing housings, enclosures, shallow cups, and formed sheet‑metal components. Manufacturers benefit from reduced tool wear, improved repeatability, and the ability to adapt the press to different materials and thicknesses.
General fabrication shops value the Single‑Point Straight‑Sided Servo Press for its versatility and ability to handle a wide range of stamping and forming tasks. The rigid frame and servo‑controlled motion make it ideal for producing brackets, plates, clips, mounting hardware, and precision metal parts. The programmable stroke allows operators to optimize forming profiles for blanking, bending, coining, embossing, and light forming operations. The straight‑sided design ensures consistent accuracy, while the servo system enhances flexibility for both short‑run and continuous production. Its combination of rigidity, precision, and programmability makes it a dependable machine for modern fabrication environments.
Frequently Asked Questions about Single Point Straight-Sided Servo Press
A: A straight‑sided servo press provides significantly greater rigidity and structural stability compared to a C‑frame design. Because the frame is fully enclosed and supported on both sides, it eliminates angular deflection and maintains perfect slide alignment under load. This makes it ideal for high‑precision stamping, progressive die work, and applications where even slight misalignment can affect part quality. The servo drive system enhances this stability by allowing operators to program custom stroke profiles, forming speeds, dwell positions, and approach distances. The result is improved dimensional accuracy, reduced tool wear, and consistent performance across long production runs. For manufacturers who require maximum precision and repeatability, a straight‑sided servo press offers a superior platform.
A: A single‑point straight‑sided servo press is ideal for small to medium‑sized components that require tight tolerances and consistent forming pressure. The single‑point configuration provides a clean, centered force path, while the straight‑sided frame ensures minimal deflection during stamping or forming. This combination delivers exceptional slide parallelism and repeatable accuracy. The servo system adds flexibility by allowing operators to adjust forming velocity, dwell time, and stroke profiles to match the needs of each job. This improves part quality, reduces shock loads, and extends tool life. Manufacturers choose this press when they need a rigid, high‑precision machine capable of handling demanding applications with maximum control and efficiency.
A: This press is ideal for producing small and medium‑sized components that require high precision, clean edges, and consistent dimensional accuracy. Common applications include electrical connectors, terminals, brackets, housings, EV battery components, appliance hardware, and precision automotive stampings. The straight‑sided frame ensures stable slide motion, while the servo drive allows operators to fine‑tune forming profiles for blanking, piercing, bending, coining, and shallow forming. Its ability to maintain perfect alignment under load makes it especially effective for progressive dies and multi‑hole operations. Whether working with steel, aluminum, copper, or specialty alloys, this press delivers the accuracy and repeatability required for demanding production environments.
A:
Yes — the Single‑Point Straight‑Sided Servo Press is designed for seamless integration with modern automation systems. Its straight‑sided frame provides a stable, rigid platform for coil feeders, straighteners, servo roll feeds, transfer systems, and robotic loading or unloading. The programmable servo motion allows precise synchronization with external automation equipment, improving cycle times and reducing handling errors. This makes the press ideal for high‑volume progressive stamping lines as well as hybrid workflows that combine manual and automated operations. Manufacturers benefit from increased throughput, reduced labor costs, and consistent part quality. The press’s rigidity and servo flexibility make it a strong foundation for fully automated production environments.
A: The MSC‑SV Series serves a wide range of industries that require precision stamping, high‑speed production, and programmable forming control. Automotive suppliers use it for brackets, clips, terminals, and lightweight structural components. Electrical and electronics manufacturers rely on it for connectors, contact plates, and thin‑gauge stampings. Appliance and consumer goods producers use it for hinges, brackets, housings, and internal hardware. General metal fabrication shops value its versatility for blanking, piercing, bending, and shallow forming. Because the servo system adapts to different materials and tooling requirements, the press is suitable for both high‑volume production and high‑mix environments where flexibility and accuracy are essential.
Yes — straight‑sided servo presses are available to customers throughout the United States, Canada, and Mexico. Many North American manufacturers rely on this press type for high‑precision stamping, progressive die work, and advanced forming applications that require exceptional accuracy and repeatability. Regional availability ensures faster delivery, reliable technical support, and easy access to replacement parts, helping reduce downtime and improve long‑term productivity. Customers can choose from multiple tonnage capacities, bed sizes, stroke lengths, and automation options to match their production needs. For facilities seeking a high‑performance servo press with strong regional support, North American‑supplied straight‑sided presses offer a dependable and efficient solution.
